Drive units
1x 25mm (1 in) Nautilus™ swirl loaded aluminium dome tweeter
1x 150mm (6 in) blue Kevlar® cone bass/midrange
Frequency range (-6dB)
35Hz – 50kHz
Sensitivity SPL (2.83V, 1m)
86dB
Nominal Impedance
8Ω (4.8Ω)
Recommended Amplifier Power
25 – 100w
Pre-mount kit
PMK C6
Back Box
BB6C or BB6W
Frame Diameter
240mm (9.5in)
Cut-out diameter
202mm (8in)
Depth behind surface (.5 minimum wall)
92mm (3.6 in)
Protrusion
7mm (0.3in)
